Hettich Pull Out Shelf - Wall Unit (W 686 mm x D 250 mm x H 41 mm, Cab. 750 mm)
Overview
The Hettich Pull Out Shelf - Wall Unit is a kitchen cabinet fitting designed as a functional and visually pleasing alternative to fixed wooden shelves. It is built for wall-mounted kitchen units with a 750 mm carcass width and mounts with KA telescopic or Quadro runners. The product is manufactured by Hettich India Pvt Ltd and falls under the Kitchen Accessories > Special Solutions category.
What It Does
This pull-out shelf converts a static wall cabinet shelf into a sliding, accessible unit. It is intended for kitchen wall units where easy access to stored items is needed without reaching deep into a fixed shelf.
Key Specifications
| Attribute | Detail |
|---|---|
| Width | 686 mm |
| Depth | 250 mm |
| Height of moving shelf | 41 mm |
| Cabinet carcass width | 750 mm (also available in 600 mm variant) |
| Loading capacity | 30–40 kg |
| Material | Stainless Steel |
| Finish | Chrome Plate |
| Country of origin | India |
| Manufacturer | Hettich India Pvt Ltd |
| Package dimensions | 70 x 27 x 10 cm (WxDxH) |
| Package contents | 1 Wire Basket, 1 Plastic Logo |
| Unit | Set (1 Number) |
| Optional accessory | Plastic bottom |
Pricing and Availability
Note: Runners and clamps are ordered separately and must be matched to the shelf specification.
Who It Helps
- Kitchen fabricators and modular kitchen installers sourcing wall-unit hardware
- Homeowners upgrading wall cabinets from fixed shelves to pull-out access
- Interior designers specifying Hettich fittings for kitchen projects
Buyer Questions This Page Should Answer
What cabinet size does this shelf fit?
It is designed for wall units with a 750 mm carcass width, with a 600 mm width variant also available under SKU 9209346_P.
What is the weight capacity?
The shelf supports a loading capacity of 30–40 kg.
What material and finish does it use?
Stainless steel construction with a chrome plate finish.
Does it include runners?
No. Runners (KA telescopic or Quadro) and clamps must be ordered separately and matched to this shelf specification.
What's included in the package?
One wire basket and one plastic logo per set, packaged in a 70 x 27 x 10 cm box.
Resources
Current product facts
Last checked by Readable: 2026-10-09T18:45:45.623Z
- Product: Hettich Pull Out Shelf - Wall unit
- Brand: Hettich
- Category: Kitchen Accessories > Special Solutions
- SKU: 9209346_P
- Price: ₹2,508 (MRP ₹2,950)
- Availability: InStock
- Variants: Cabinet Size: Carcass Width - 600 mm, Cabinet Size: Carcass width - 750 mm
