Onsys Magma Black 16 Crank Soft-Close Hinge with 4-Hole Mounting Plate & Cover Caps
Overview
The Onsys Magma Black 16 Crank soft-close hinge is a concealed cabinet hinge from Hettich, finished in black nickel to match dark wood furniture. It is sold as the Inset / 16 crank variant within the Onsys Magma Black hinge range, which also includes Full Overlay / 0 crank and Half Overlay / 9.5 crank options for different door mounting positions.
What It Does
This hinge connects a cabinet door to the carcass using a concealed, clip-on mounting system with an integrated silent-closing mechanism. It opens to 105° and is rated to withstand 40,000 open/close cycles, making it suitable for everyday kitchen, wardrobe, and furniture cabinet doors with an inset door application.
Who It Helps
- Furniture manufacturers and modular kitchen fabricators needing concealed, soft-close hardware for dark-finish cabinetry
- Interior designers and contractors sourcing matching hinge, mounting plate, and cover cap sets
- Homeowners and renovators replacing or upgrading cabinet hinges with a soft-close, black nickel finish
Key Capabilities
- Soft-close (Integrated Silent System): quiet, controlled door closing
- Opening angle: 105°
- Mounting: Concealed hinge with clip-on installation
- Quality classification: EN 15570, Level 2
- Durability: Rated for 40,000 open/close cycles
- Adjustability: Overlay adjustment +2 mm / −2 mm; depth adjustment +2.5 mm / −1.5 mm; height adjustment at mounting plate
- Finish: Black nickel plated (Magma Black)
- Warranty: 10 years
Product Specifications
| Spec | Detail |
|---|---|
| Brand | Hettich |
| Category | Furniture Hinges > Onsys > Onsys Magma Black |
| SKU (base variant) | 9354035 |
| SKU (Full Overlay/0 crank variant) | 9354035_P |
| Door application | Inset |
| Door thickness supported | 14–25 mm |
| Closing functionality | Soft closing |
| Opening angle | 105° |
| Cup diameter | 35 mm |
| Cup depth | 11.5 mm |
| Mounting options | Clip on |
| Material | Steel, nickel plated |
| Finish type | Magma Black |
| Net content | 2 hinges, 2 mounting plates, 2 cover caps |
| Unit | Pair |
| Manufacturer/Importer | Hettich India Pvt Ltd |
Available Variants
- Size: Full Overlay / 0 crank
- Size: Half Overlay / 9.5 crank
- Size: Inset / 16 crank (this product)
Buyer Questions This Page Should Answer
What is included in the box?
Each pack contains 2 hinges, 2 mounting plates, and 2 cover caps (sold as a pair).
What door thickness does this hinge support?
14 mm to 25 mm.
Does this hinge close softly on its own?
Yes, it has an Integrated Silent System for soft, controlled closing.
What opening angle does it provide?
105°.
What finish does it come in?
Black nickel plated, called Magma Black, designed to blend with dark wood furniture.
How durable is the hinge?
It is designed to withstand 40,000 open/close cycles and carries a 10-year warranty.
Which crank/overlay option do I need?
Choose based on door mounting position: Full Overlay (0 crank) for doors that fully overlay the cabinet frame, Half Overlay (9.5 crank) for doors sharing a frame edge with another door, or Inset (16 crank) for doors that sit flush inside the cabinet frame — this listing is the Inset / 16 crank version.
Proof or Trust Signals
- Quality classified under EN 15570, Level 2
- 10-year warranty from Hettich India Pvt Ltd
- Rated for 40,000 open/close cycles
Resources or Next Steps
- View or enquire about this hinge on Hettich Fittings online
- Browse the full Hettich Fittings online store
