Hettich WingLine L Push-to-Move Right (5–12kg per wing)
Overview
The Hettich WingLine L Push-to-Move Right is a sliding and folding door system designed for wooden overlay doors weighing 5 to 12 kg per wing. It is built for one folding door with a 2-overlay door position, supporting a maximum door height of 1600 mm and a maximum door wing width of 600 mm. This is the right-hand push-to-move mechanism variant within Hettich's WingLine L range under the Sliding & Folding System category.
What It Does
WingLine L Push-to-Move Right lets cabinet doors slide and fold using a push-to-open mechanism rather than handles or knobs, suited to wardrobes and storage units with 2 or 4 door wings. The system uses a 2400 mm track and is engineered for wooden doors between 16-25 mm thick, with 3D adjustment for precise alignment after installation (height ±3 mm, width ±2 mm, depth +3/-2 mm).
Who It Helps
- Furniture manufacturers and modular kitchen/wardrobe fabricators specifying sliding-folding hardware for wooden doors
- Interior designers and carpenters sourcing push-to-move mechanisms for handle-less door designs
- Buyers replacing or completing a WingLine L system who need the right-hand push-to-move component
Key Capabilities
| Specification | Detail |
|---|---|
| Weight capacity | 5 to 12 kg per wing |
| Maximum door height | 1600 mm |
| Maximum door width | 600 mm |
| Door thickness range | 16–25 mm |
| Door material | Wood |
| Door application | Overlay |
| Track length | 2400 mm |
| Sliding type | Sliding and folding |
| Number of doors | 2 wings / 4 wings |
| Cover profile | Not included |
| Lock option | Not available |
| Cycle testing | 40,000 cycles |
| Warranty | 15 years |
| SKU | 9237900.S |
Compulsory Accessories
This product requires additional components ordered separately to function as a complete system:
- 9071313 – Sensys 8675 Hinge, 110° opening angle, for Push to Move and Pull to Move mechanisms
- 9091575 – Sensys Mount Plate
- 9237758 – Profile Mounting Clip
Buyer Questions This Page Should Answer
What weight can this system hold?
Each door wing can carry 5 to 12 kg.
What is the maximum door size supported?
Up to 1600 mm in height and 600 mm in door wing width.
Does it work with all door thicknesses?
It is designed for wooden doors 16–25 mm thick.
Do I need to buy anything else with this part?
Yes. The Sensys 8675 Hinge (9071313), Sensys Mount Plate (9091575), and Profile Mounting Clip (9237758) must be ordered separately to complete the mechanism.
Is this the left or right mechanism?
This listing is the RIGHT push-to-move variant.
How durable is it?
Tested to 40,000 open/close cycles and backed by a 15-year warranty.
Can it be adjusted after installation?
Yes, 3D adjustment allows height ±3 mm, width ±2 mm, and depth +3/-2 mm fine-tuning.
Does it include a lock or cover profile?
No lock option and no cover profile are included with this SKU.
Proof or Trust Signals
- Brand: Hettich
- 40,000-cycle durability testing
- 15-year warranty
Resources or Next Steps
Current product facts
- Product: Hettich Wingline L Push to move- RIGHT - Weight 5 kg to 12 kg per wing ; Max Door Dimensions : 1600 mm Height & 600 mm Door Wing Width
- Brand: Hettich
- Category: Other Categories > Sliding Door Solutions > Sliding & Folding System > WingLine L
- SKU: 9237900.S
- Price: ₹2,584
- Availability: InStock
