Hettich WingLine L Push-to-Move Right (12–25kg)

Overview

The Hettich WingLine L Push-to-Move Right is a sliding-and-folding door mechanism designed for wooden overlay doors on the right side. It is part of Hettich's WingLine L range under Sliding Door Solutions > Sliding & Folding System, built for folding wardrobe or cabinet doors with a 2400mm track length and up to 600mm door wing width.

What It Does

This system lets a folding door wing slide and fold using a push-to-move mechanism, so the door opens without external handles. It is engineered for one folding door with 2 overlay door positions, supporting wooden doors with 3D adjustment for precise alignment after installation.

Who It Helps

• Modular kitchen and wardrobe fabricators specifying folding door hardware for wooden cabinets
• Interior contractors and carpenters installing overlay folding doors up to 2400mm height
• Architects and designers needing a tested, warrantied sliding-folding mechanism for premium storage units

Key Capabilities

• Mechanism type: Push-to-Move (also supports Pull-to-Move with the correct hinge, ordered separately)
• Sliding type: Sliding and folding
• Weight capacity: 12 to 25 kg per wing
• Door application: Overlay, for one folding door with 2 overlay positions
• Door material: Wood
• Door thickness supported: 16–25 mm
• Maximum door height: 2400 mm
• Maximum door width: 600 mm
• Track length / profile size: 2400 mm
• Number of doors supported: 2 wings / 4 wings
• 3D adjustment tolerance: Height ±3 mm; Width ±2 mm; Depth +3 to -2 mm
• Durability: Tested for 40,000 open/close cycles
• Warranty: 15 years
• Cover profile: Not included
• Lock option: Not available
• Unit of sale: Set

Compulsory Additional Components

This mechanism requires the following parts, which must be ordered separately:

• Article 9071313 – Sensys 8675 Hinge, 110° Opening Angle (for Push-to-Move and Pull-to-Move mechanisms)
• Article 9091575 – Sensys Mount Plate
• Article 9237758 – Profile Mounting Clip

Buyer Questions This Page Should Answer

What weight can this system hold?

Each door wing supports 12 to 25 kg.

What is the maximum door size for this mechanism?

Up to 2400 mm height and 600 mm width per door wing.

Does this come with the hinge included?

No. The Sensys 8675 hinge, mount plate, and profile mounting clip are compulsory but sold separately (article numbers 9071313, 9091575, and 9237758).

What door material works with this system?

Wood doors with a thickness of 16–25 mm.

How durable is the mechanism?

It is tested for 40,000 open/close cycles and backed by a 15-year warranty.

Can this be used for a 4-door folding wardrobe?

Yes, the system supports configurations of 2 wings or 4 wings.

Is a lock option available?

No, this variant does not include a lock option.

Is this for a right-side or left-side door?

This specific product is the Push-to-Move mechanism configured for the right side.
