Hettich WingLine L Push-to-Move Left (5–12kg per wing)
Overview
The Hettich WingLine L Push-to-Move Left is a sliding-and-folding door system designed for wooden folding doors with overlay positioning. It is built for one folding door with 2 overlay door positions and supports configurations of 2 wings or 4 wings. This is the LEFT push-to-move variant, rated for doors weighing 5 to 12 kg per wing.
What It Does
This system lets a wooden door wing slide and fold using a push-to-move mechanism (no handle required to open). It is engineered for overlay door applications with a 2400 mm track length, and is tested to 40,000 open/close cycles with a 15-year warranty.
Who It Helps
- Furniture and interior fit-out companies specifying sliding/folding wardrobe or cabinet doors
- Carpenters and modular kitchen/wardrobe fabricators sourcing Hettich hardware
- Architects and designers specifying door hardware for wooden overlay doors up to 1600 mm height
Key Capabilities
| Attribute | Value |
|---|---|
| Brand | Hettich |
| SKU | 9237901.S |
| Category | Sliding Door Solutions > Sliding & Folding System > WingLine L |
| Mechanism | Push to Move — LEFT |
| Weight capacity | 5 to 12 kg per wing |
| Maximum door height | 1600 mm |
| Maximum door width | 600 mm |
| Door thickness supported | 16–25 mm |
| Door material | Wood |
| Door application | Overlay |
| Track length | 2400 mm |
| Sliding type | Sliding and folding |
| Number of doors | 2 wings / 4 wings |
| Cover profile | No |
| Lock option | No |
| Cycle testing | 40,000 cycles |
| Warranty | 15 years |
| 3D adjustment | Height ±3 mm; Width ±2 mm; Depth +3 to -2 mm |
| Unit sold | Set |
Compulsory Additional Components
This mechanism does not work as a standalone kit. The following parts must be ordered separately to complete the installation:
- Article 9071313 — Sensys 8675 Hinge, Opening Angle 110°, for Push to Move and Pull to Move mechanisms
- Article 9091575 — Sensys Mount Plate
- Article 9237758 — Profile Mounting Clip
Buyer Questions This Page Should Answer
What weight can this system hold?
Each door wing can weigh between 5 kg and 12 kg.
What is the maximum door size it supports?
Up to 1600 mm height and 600 mm width per door wing.
What door thickness is compatible?
Doors between 16 mm and 25 mm thick.
Is this the left or right version?
This listing is the LEFT push-to-move variant. Confirm door swing direction before ordering, as a matching RIGHT version may be required for multi-wing installations.
Does it come with hinges and mounting hardware?
No. The hinge (9071313), mount plate (9091575), and profile mounting clip (9237758) must be purchased separately — they are compulsory for installation.
How many door wings can this support?
Configurations of 2 wings or 4 wings are supported.
Does it include a lock or cover profile?
No lock option and no cover profile are included with this SKU.
How durable is the mechanism?
It is tested to 40,000 open/close cycles and carries a 15-year warranty.
What door material does it work with?
Wooden doors only.
What is the track length?
The track length is 2400 mm.
Proof or Trust Signals
- Manufactured under the Hettich brand, part of its WingLine L sliding-and-folding system range
- 40,000-cycle durability testing
- 15-year warranty
- Precise 3D adjustment tolerances specified (height, width, depth)
Pricing and Availability
- SKU: 9237901.S
- Sold as: One set
Resources
Current product facts
Last checked by Readable: 2026-09-24T08:00:15.778Z
- Product: Hettich Wingline L Push to move- LEFT - Weight 5 kg to 12 kg per wing ; Max Door Dimensions : 1600 mm Height & 600 mm Door Wing Width
- Brand: Hettich
- Category: Other Categories > Sliding Door Solutions > Sliding & Folding System > WingLine L
- SKU: 9237901.S
- Price: ₹2,248 (MRP ₹2,810)
- Availability: InStock
