Hettich WingLine L Pull-to-Move Right (5–12kg per wing)

Overview

The Hettich WingLine L Pull-to-Move Right is a sliding and folding door fitting system designed for folding doors made of wood. It is built for the right-wing side of a two-wing folding door and supports a weight capacity of 5 to 12 kg per wing. This variant is part of Hettich's WingLine L range under Sliding Door Solutions > Sliding & Folding System.

What It Does

This mechanism lets a wooden folding door wing slide and fold using a pull-to-move (touch-to-open) action, so the door can be opened without handles. It is engineered for overlay door positioning and includes 3D adjustment for fine-tuning alignment after installation.

Who It Helps

• Furniture manufacturers and carpenters building wardrobes or cabinets with folding door fronts.
• Interior fit-out professionals specifying Hettich hardware for wooden folding doors.
• Buyers who need a right-wing pull-to-move mechanism to pair with a matching left-wing unit for a complete 2-wing or 4-wing folding door set.

Key Capabilities

• Mechanism type: Pull-to-move (touch-latch), right-wing orientation
• Weight capacity: 5 to 12 kg per wing
• Door configuration: For one folding door with 2 wings (also listed for 2 wings / 4 wings)
• Door position: Overlay
• Door material: Wood only
• Door thickness supported: 16–25 mm
• Maximum door height: 1600 mm
• Maximum door wing width: 600 mm
• Track length: 2400 mm
• 3D adjustment range: Height ±3 mm; Width ±2 mm; Depth +3 to -2 mm
• Durability testing: Tested for 40,000 open/close cycles
• Cover profile: Not included
• Lock option: Not available

Compulsory Companion Parts

This fitting requires separate ordering of the following components to function as a complete system:

• Article 9071313 – Sensys 8675 Hinge, 110° opening angle, for Push to Move and Pull to Move mechanisms
• Article 9091575 – Sensys Mount Plate
• Article 9237758 – Profile Mounting Clip

Buyer Questions This Page Should Answer

What is the weight capacity of this fitting?

Each wing can carry 5 to 12 kg.

What door sizes does it fit?

Maximum door height is 1600 mm and maximum door wing width is 600 mm, with a door thickness range of 16–25 mm.

Does this include the hinge and mounting hardware?

No. The hinge (9071313), mount plate (9091575), and profile mounting clip (9237758) must be ordered separately — they are compulsory for installation.

Is this for the left or right wing?

This SKU (9237900.G) is the right-wing pull-to-move unit. A matching left-wing unit is needed for a complete two-wing door.

What material of door does it support?

Wood doors only.

How durable is the mechanism?

It has been tested through 40,000 open/close cycles.

Can the fitting be adjusted after installation?

Yes, it offers 3D adjustment: height ±3 mm, width ±2 mm, and depth +3 mm to -2 mm.
