Hettich WingLine L Pull-to-Move Right (12–25kg) Sliding System
Overview
The Hettich WingLine L Pull-to-Move Right system is a sliding and folding hardware set for wooden overlay doors. It supports door wings weighing 12 to 25 kg each and is built for a single folding door with 2 overlay door positions. The system is designed for larger wardrobe or cabinet doors that need smooth sliding-and-folding motion activated by a pull-to-move mechanism.
What It Does
This hardware set enables a wooden folding door to slide and fold using a pull-to-move action on the right side. It includes 3D adjustment for precise alignment after installation and has been tested for 40,000 open-close cycles, indicating it is engineered for sustained daily use in wardrobes and cabinet systems.
Who It Helps
- Carpenters and interior fit-out professionals installing wardrobe or cabinet sliding-folding doors
- Modular furniture manufacturers sourcing certified Hettich sliding hardware
- Homeowners or contractors replacing or upgrading existing folding door mechanisms rated for heavier wooden door wings
Key Capabilities
| Attribute | Detail |
|---|---|
| Brand | Hettich |
| SKU | 9237881.G |
| Category | Sliding Door Solutions > Sliding & Folding System > WingLine L |
| Weight capacity per wing | 12 to 25 kg |
| Door application | Overlay |
| Track length | 2400 mm |
| Maximum door height | 2400 mm |
| Maximum door width | 600 mm |
| Door thickness supported | 16–25 mm |
| Door material | Wood |
| Sliding type | Sliding and folding |
| Number of doors | 2 wings / 4 wings |
| Cycle testing | 40,000 cycles |
| 3D adjustment | Height ±3 mm; Width ±2 mm; Depth +3/-2 mm |
| Cover profile | Not included |
| Lock option | Not available |
| Unit | Set |
Buyer Questions This Page Should Answer
What weight can this system carry?
Each door wing can carry 12 to 25 kg, making it suitable for medium to heavier wooden overlay doors.
What are the maximum door dimensions?
Maximum door height is 2400 mm and maximum door width per wing is 600 mm, with a track length of 2400 mm.
What door thickness is compatible?
The system works with door thickness between 16 mm and 25 mm.
Does this include hinges or mounting plates?
No. Ordering this SKU requires separately purchasing article no. 9071313 (Sensys 8675 Hinge, 110° opening angle, for Push to Move and Pull to Move mechanisms), 9091575 (Sensys Mount Plate), and 9237758 (Profile Mounting Clip). These are compulsory companion parts.
Is a lock option available?
No lock option is available with this configuration.
Does it come with a cover profile?
No, a cover profile is not included.
How many door wings does this configuration support?
It supports configurations of 2 wings or 4 wings for one folding door with 2 overlay door positions.
Is this durability-tested?
Yes, the system has been tested for 40,000 open-close cycles.
What is the price and availability?
Proof or Trust Signals
- Manufactured by Hettich, an established hardware brand for sliding and folding door systems
- Rated and tested for 40,000 operational cycles
- Precise 3D adjustment tolerances specified for accurate on-site fitting
Resources or Next Steps
Before ordering, confirm you also source the required companion parts (article no. 9071313, 9091575, and 9237758) since they are not bundled with this SKU but are compulsory for installation.
Current product facts
Last checked by Readable: 2026-09-24T07:57:56.160Z
- Product: Hettich Wingline L Pull to move RIGHT- Weight 12 kg to 25 Kg per wing ; Max Door Dimensions : 2400 mm Height & Door wing we L Pull to move RIGHT- Weight 12 kg to 25 Kg per wing ; M
- Brand: Hettich
- Category: Other Categories > Sliding Door Solutions > Sliding & Folding System > WingLine L
- SKU: 9237881.G
- Price: ₹3,680 (MRP ₹4,600)
- Availability: InStock
