Hettich WingLine L Pull-to-Move LEFT (5–12 kg)

Overview

The Hettich WingLine L Pull-to-Move LEFT is a sliding and folding door hardware set designed for wooden folding doors on the left side of a wardrobe or cabinet opening. It supports one folding door made up of 2 wings, each carrying 5 to 12 kg, and is built for overlay door installations.

• Brand: Hettich
• Category: Sliding Door Solutions > Sliding & Folding System > WingLine L
• SKU: 9237901.G

What It Does

This mechanism enables a folding door with 2 wings to slide and fold along a track, using a pull-to-move (handle-free push/pull opening) action on the left-hand side of the cabinet. It is engineered for overlay door positioning on wooden doors and includes 3D adjustment for precise alignment after installation.

Who It Helps

• Furniture manufacturers and modular kitchen/wardrobe fabricators installing folding wooden doors
• Interior fit-out contractors needing a tested, weight-rated folding door mechanism
• Buyers replacing or upgrading sliding/folding wardrobe hardware to a pull-to-move (handle-less) system

Key Capabilities

• Weight capacity: 5 to 12 kg per wing
• Door material: Wood
• Door thickness supported: 16–25 mm
• Maximum door height: 1600 mm
• Maximum door width: 600 mm (per wing)
• Track length: 2400 mm
• Door application: Overlay
• Sliding type: Sliding and folding
• Number of doors: 2 wings / 4 wings
• 3D adjustment range: Height ±3 mm; Width ±2 mm; Depth +3 to -2 mm
• Durability: Tested for 40,000 open/close cycles
• Unit of sale: Set
• Cover profile included: No
• Lock option: No

Compatibility and Required Add-On Parts

This product requires additional components ordered separately to complete a working installation:

Note: These three parts are a compulsory order alongside the main WingLine L Pull-to-Move LEFT set — the mechanism will not function as a complete folding door system without them.

Buyer Questions This Page Should Answer

What weight can this hardware hold?

Each door wing can carry 5 to 12 kg, suitable for standard wooden wardrobe or cabinet folding doors.

What is the maximum door size it supports?

Up to 1600 mm in height and 600 mm in width per door wing.

Is this for left- or right-hand doors?

This specific SKU (9237901.G) is the LEFT-side Pull-to-Move version. A separate right-side version would be required for the opposite door.

Does it work with any door thickness?

It is designed for door thickness between 16 mm and 25 mm.

Do I need to buy anything else with this?

Yes. The Sensys 8675 hinge, Sensys mount plate, and profile mounting clip are compulsory separate purchases (article numbers 9071313, 9091575, and 9237758).

How durable is the mechanism?

It has been tested for 40,000 open/close cycles.

Does it include a lock or cover profile?

No, this set does not include a lock option or a cover profile.

What door configuration does it support?

One folding door made of 2 wings (systems can extend to 4 wings), mounted in an overlay door position with a 2400 mm track length.

Proof or Trust Signals

• Manufactured by Hettich, a recognized furniture hardware brand
• Cycle-tested to 40,000 operations for durability assurance
• Precise 3D adjustment tolerances specified for professional installation accuracy
