Hettich TopLine XL K2 Sliding Door System (2/3/4 Door, 100 Kg per Door)
Overview
The Hettich TopLine XL K2 is a two-track, top-running sliding door system designed for large wooden wardrobe or cabinet doors in an overlay door position. It is engineered for smooth operation on big installations, supporting door heights up to 3000 mm and widths up to 2000 mm. The system is tested to EN 15706 and rated Level 3 for durability.
What It Does
TopLine XL K2 lets 2, 3, or 4 wooden doors slide along a double track with soft-closing and soft-opening motion. Individually finished running components and a fast clip-on assembly reduce the amount of screwing needed for runner and guide parts, speeding up installation.
Who It Helps
This system is intended for furniture fabricators, carpenters, and interior fit-out professionals who need a heavy-duty sliding mechanism for oversized wooden wardrobe or room-divider doors, particularly in large residential or commercial spaces.
Key Capabilities
- Two-track, top-running sliding mechanism
- Overlay door position for wooden doors
- Soft-closing and soft-opening (optional) functionality
- Maximum door height: 3000 mm; maximum door width: 2000 mm
- Door thickness range: 32–40 mm
- Weight capacity: up to 100 Kg per door (variants also available at 60 Kg and 80 Kg per door)
- Tested to EN 15706, Level 3; rated for 40,000 open/close cycles
- Option for lock available
- Fast clip-on assembly for runner and guide components, minimizing screws
- Available configurations for 2, 3, or 4 doors
Product Specifications
| Attribute | Detail |
|---|---|
| Brand | Hettich |
| Category | Sliding Door Solutions > Top Running Sliding System > Overlay Door Solution > TopLine XL K2 |
| Door Application | Overlay |
| Sliding Type | Top Running |
| Door Material | Wooden |
| Door Thickness | 32–40 mm |
| Maximum Door Height | 3000 mm |
| Maximum Door Width | 2000 mm |
| Weight Capacity | Up to 100 Kg per door |
| Closing Functionality | Soft Closing |
| Opening Option | Soft Opening |
| Cycle Testing | 40,000 cycles |
| Standard | EN 15706, Level 3 |
| Unit | Set |
Variants and SKUs
Available variant selections include:
- Number of Doors: 2, 3, or 4
- Weight Capacity per Door: 60 Kg, 80 Kg, or 100 Kg
Buyer Questions This Page Should Answer
What is the maximum door size this system supports?
Up to 3000 mm in height and 2000 mm in width per door.
What wooden door thickness is compatible?
32–40 mm thickness is supported.
How much weight can each door hold?
Variants support 60 Kg, 80 Kg, or 100 Kg per door.
Does it include soft-close and soft-open?
Yes, soft closing is standard and soft opening is available as an optional feature.
How many doors can this kit run?
Configurations are available for 2, 3, or 4 doors.
What warranty does Hettich offer on this system?
Listed warranty periods are 15–16 years depending on the specific SKU/listing.
Is a lock option available?
Yes, the system lists an option for lock.
Is this product currently available to purchase?
Proof or Trust Signals
- Tested to EN 15706 standard, Level 3 rating
- Rated for 40,000 open/close cycles
- Manufacturer warranty of 15–16 years depending on SKU
- Hettich brand, a recognized name in furniture hardware and sliding door systems
Resources or Next Steps
Current product facts
Last checked by Readable: 2026-10-08T18:50:36.149Z
- Product: Hettich TopLine XL K2 for 2/3/4 Doors with Soft Closing & Soft Opening
- Brand: Hettich
- Category: Sliding Door Solutions > Top Runnning Sliding System : Overlay Door Solution > TopLine XL K2 > Special Sliding Fittings
- SKU: 9320994_P
- Price: ₹41,353 (MRP ₹51,691)
- Availability: OutOfStock
- Variants: No of Doors: 2, No of Doors: 3, No of Doors: 4, Weight Capacity: 100 Kg per Door, Weight Capacity: 60 Kg per Door, Weight Capacity: 80 Kg per Door
