Hettich TopLine L Loft 3-Door STB-12 (25mm)
Overview
The Hettich TopLine L Loft Version is a 2-track, top-running sliding door system designed for 3-door overlay wardrobe and cabinet configurations. This variant uses STB-12 fittings (screw from front) and is built for 25 mm thick door panels, supporting up to 50 kg per door. It is part of Hettich's Sliding Door Solutions range, specifically the Top Running Sliding System (Overlay Door Solution) under the TopLine L Loft version.
What It Does
This hardware kit enables smooth, quiet sliding operation for wooden or aluminium-framed wardrobe doors using a top-running (top-hung) track mechanism. It includes Hettich's Silent System technology, which cushions the door during closing, opening, and collision to reduce noise and wear.
Who It Helps
- Furniture manufacturers and modular wardrobe fabricators building 3-door sliding systems
- Interior designers and carpenters specifying sliding door hardware for large wardrobes or lofts
- Homeowners and contractors sourcing replacement or upgrade sliding mechanisms for wooden or aluminium-framed doors up to 2600 mm height
Key Capabilities
- Sliding type: Top running, 2-track system
- Door application: Overlay (widely opened or offset doors, 34 mm offset; optional flush doors at 0 mm offset)
- Silent System: Dampened closing, opening, and colliding motion
- Durability tested: DIN EN15706, Level 3, rated for 40,000 opening-closing cycles
- Door material compatibility: Wood and aluminium-framed doors
- Closing functionality: Soft closing (soft opening and colliding optional)
- Warranty: 15 years
Specifications
| Attribute | Value |
|---|---|
| SKU | 9333865.G |
| Door application | Overlay |
| Track length | 3000 mm |
| Weight capacity per door | 50 kg |
| Door thickness | 25 mm |
| Top panel thickness | ≤ 22 mm |
| Maximum door width | 550–2000 mm |
| Maximum door height | 2600 mm |
| Cycle testing | 40,000 cycles |
| Closing functionality | Soft closing |
| Opening (optional) | Soft opening and colliding optional |
| Cover profile | No |
| Door material | Wood / Aluminium |
| Unit | Set |
Pricing and Availability
| Detail | Value |
|---|---|
| Brand | Hettich |
Buyer Questions This Page Should Answer
What is STB-12 in this product name?
STB-12 refers to the front-screw fitting method used to attach this sliding hardware kit to the door panel.
What door thickness does this kit support?
This kit is designed for 25 mm thick door panels, with a top panel thickness limit of 22 mm or less.
How much weight can each door carry?
Each door supported by this system can carry up to 50 kg.
What is the maximum door size this system supports?
Maximum door height is 2600 mm, and width ranges from 550 mm to 2000 mm.
Is this suitable for aluminium-framed doors?
Yes, the system supports both wooden doors and aluminium-framed doors.
Does it include soft-close functionality?
Yes, soft closing is standard; soft opening and anti-collision damping are available as optional features via the Silent System.
How durable is this sliding system?
It is tested to DIN EN15706, Level 3, verified for 40,000 opening-closing cycles.
What warranty is offered?
Hettich provides a 15-year warranty on this product.
Does this kit include a cover profile?
No, a cover profile is not included with this configuration.
Proof or Trust Signals
- Manufactured by Hettich, a recognized furniture hardware brand
- Independently tested to DIN EN15706, Level 3 standard for 40,000 cycles
- Backed by a 15-year warranty
Resources or Next Steps
Current product facts
Last checked by Readable: 2026-09-24T07:58:23.898Z
- Product: Hettich TopLine L Loft Version (3 Door 25 mm thickness) with STB 12 (Screw from front) - Weight 50 kg per door; Max. Door Dimensions: Height 2600 mm & Width 550-2000 mm
- Brand: Hettich
- Category: Sliding Door Solutions > Top Runnning Sliding System : Overlay Door Solution > TopLine L Loft version > Top Runnning Sliding System : Inset Door Solution
- SKU: 9333865.G
- Price: ₹126 (MRP ₹158)
- Availability: InStock
