Hettich TopLine L Loft 2-Door Right STB-12 (25mm)
Overview
The Hettich TopLine L Loft Version (2 Door, Front Right, 25mm thickness) with STB-12 fitting is a top-running sliding door system designed for wardrobes and cabinets using wooden or aluminium-framed door panels. It uses a front-screw (STB-12) fixing method and includes Hettich's Silent System for quiet closing, opening, and collision damping. This SKU covers the right-side door component of a 2-door overlay sliding setup.
What It Does
This component is part of a 2-track, top-running sliding door mechanism that lets wardrobe doors overlap and slide smoothly along a top-mounted track. It supports overlay door positioning for widely opened doors, through offset doors (34mm offset), with an optional flush door configuration (0mm offset). The Silent System technology dampens motion in the closing, opening, and colliding directions to reduce noise and impact.
Who It Helps
- Modular kitchen and wardrobe fabricators sourcing sliding door hardware for wooden or aluminium-framed doors
- Interior designers and carpenters specifying top-running sliding systems for large-format doors
- Hardware distributors and retailers stocking Hettich sliding door components
- Builders and homeowners renovating wardrobes with door heights up to 2600mm
Key Capabilities
- 2-track, top-running sliding door system
- Compatible with wooden doors and aluminium-framed doors
- Overlay door position with 34mm offset (or optional 0mm flush offset)
- Silent System damping in closing, opening, and colliding directions
- Front screw fixing (STB-12) for door panel attachment
- Soft-closing functionality built in
Specifications
| Attribute | Value |
|---|---|
| SKU | 9333866.G |
| Brand | Hettich |
| Door Position | Overlay |
| Track Length | 3000 mm |
| Weight Capacity per Door | 50 kg |
| Door Thickness | 25 mm |
| Top Panel Thickness | ≤ 22 mm |
| Closing Functionality | Soft closing (inbuilt) |
| Cycle Testing | 40,000 open-close cycles, tested to DIN EN15706 Level 3 |
| Maximum Door Width | 2000 mm (minimum 550 mm) |
| Maximum Door Height | 2600 mm |
| Sliding Type | Top running |
| Door Material | Wood / Aluminium |
| Cover Profile | No |
| Unit | Set |
| Warranty | 15 years |
Buyer Questions This Page Should Answer
What door materials does this system support?
It is designed for wooden doors and aluminium-framed doors.
What is the maximum door size it supports?
Up to 2600 mm in height and between 550 mm and 2000 mm in width, with a weight capacity of 50 kg per door.
How is the door panel fixed to the system?
Using the STB-12 fitting, which is a front-screw fixing method — no need to access the door from behind.
Does it support soft or silent closing?
Yes. It includes Hettich's Silent System, which dampens motion during closing, opening, and collision, plus built-in soft-close functionality.
What offset options are available?
Overlay doors can be widely opened through offset doors with a 34mm offset, or optionally configured as flush doors with a 0mm offset.
How durable is this hardware?
It is tested to DIN EN15706, Level 3, for 40,000 opening-closing cycles, and comes with a 15-year warranty.
What door thickness does it accommodate?
Designed for 25mm-thick door panels, with a top panel thickness of up to 22mm.
Is this the full 2-door set or a single component?
This listing is the front-right door component (25mm thickness) of the 2-door TopLine L Loft configuration.
Proof or Trust Signals
- Tested to DIN EN15706, Level 3, for 40,000 opening-closing cycles
- 15-year manufacturer warranty
- Manufactured by Hettich, an established hardware brand for sliding and cabinet systems
Resources and Next Steps
Current product facts
Last checked by Readable: 2026-09-24T07:58:24.583Z
- Product: Hettich TopLine L Loft Version (2 Door Front Right 25 mm thickness) with STB 12 (Screw from front) - Weight 50 kg per door; Max. Door Dimensions: Height 2600 mm & Width 550-2000 mm
- Brand: Hettich
- Category: Sliding Door Solutions > Top Runnning Sliding System : Overlay Door Solution > TopLine L Loft version > Top Runnning Sliding System : Inset Door Solution
- SKU: 9333866.G
- Price: ₹126 (MRP ₹158)
- Availability: InStock
