Hettich TopLine L Loft 2-Door Right STB-11 (25mm)
Overview
The Hettich TopLine L Loft Version is a 2-track, top-running sliding door system designed for wardrobes and storage units using wooden doors or aluminium-framed doors. This specific configuration is the 2-door front right setup with STB-11 (screw from bottom) fitting, built for 25 mm thick panels and a weight capacity of 50 kg per door.
What It Does
TopLine L Loft is an overlay sliding door solution that supports widely opened doors through offset doors (34 mm offset), with an optional flush door configuration (0 mm offset). It includes Hettich's Silent System technology, which cushions the door in the closing, opening, and colliding directions for quiet, smooth operation.
Who It Helps
This system is intended for furniture fabricators, carpenters, interior fit-out contractors, and wardrobe/cabinet manufacturers who need a durable top-running sliding door mechanism for wooden or aluminium-framed doors in residential or commercial storage units.
Key Capabilities
- 2-track, top-running sliding door system
- Compatible with wooden doors and aluminium-framed doors
- Overlay door position
- Supports widely opened (offset) doors at 34 mm offset; optional flush doors at 0 mm offset
- Silent System damping in closing, opening, and colliding directions
- Soft-closing functionality built in
- Tested to DIN EN15706, Level 3 for 40,000 opening-closing cycles
- Top panel thickness up to 22 mm
- 15-year warranty
Specifications
| Attribute | Value |
|---|---|
| Brand | Hettich |
| Category | Sliding Door Solutions > Top Running Sliding System: Overlay Door Solution > TopLine L Loft version |
| SKU | 9333866.S |
| Door Position | Overlay |
| Track Length | 3000 mm |
| Weight Capacity per Door | 50 kg |
| Door Thickness | 21-25 mm |
| Closing Functionality | Soft closing (inbuilt) |
| Cycle Testing | 40,000 cycles |
| Maximum Door Width | 2000 mm (minimum 550 mm) |
| Maximum Door Height | 2600 mm |
| Sliding Type | Top running |
| Door Material | Wood / Aluminium |
| Unit | Set |
| Cover Profile | No |
| Warranty | 15 years |
Pricing & Availability
- Unit: Sold as a set
Buyer Questions This Page Should Answer
What door thickness does this system support?
It supports door thicknesses between 21-25 mm, with a top panel thickness up to 22 mm.
What is the maximum door size this fitting can handle?
Maximum door height is 2600 mm and maximum door width is 2000 mm (minimum width 550 mm).
How much weight can each door carry?
Each door in this 2-door configuration can carry up to 50 kg.
What materials can be used with this sliding system?
It works with wooden doors and aluminium-framed doors.
Does it support flush or offset door installation?
Yes. It supports widely opened (offset) doors at a 34 mm offset, with an optional flush door setting at 0 mm offset.
Is it a soft-close system?
Yes, soft-closing functionality is built in, supported by Hettich's Silent System for quiet closing, opening, and collision damping.
What durability testing has this system passed?
It is tested to DIN EN15706, Level 3, for 40,000 opening-closing cycles.
What is the warranty period?
Hettich provides a 15-year warranty on this TopLine L Loft system.
What does STB-11 mean in this product name?
STB-11 refers to the screw-from-bottom fitting method used to mount this specific configuration.
Resources
Current product facts
Last checked by Readable: 2026-10-10T18:50:36.691Z
- Product: Hettich TopLine L Loft Version (2 Door Front Right 25 mm thickness) with STB 11 (Screw from bottom) - Weight 50 kg per door; Max. Door Dimensions: Height 2600 mm & Width 550-2000 m
- Brand: Hettich
- Category: Sliding Door Solutions > Top Runnning Sliding System : Overlay Door Solution > TopLine L Loft version
- SKU: 9333866.S
- Price: ₹126 (MRP ₹158)
- Availability: InStock
