Hettich TopLine L Loft 2-Door Right STB-12 (20mm)
Overview
The Hettich TopLine L Loft Version is a 2-track, top-running sliding door system designed for wardrobes and cabinet fronts using wooden or aluminium-framed doors. This specific configuration is the 2-Door Front Right, STB-12 (screw from front) variant, built for 20 mm thick panels and rated for up to 50 kg per door. It is part of Hettich's Sliding Door Solutions range, under Top Running Sliding System > Overlay Door Solution > TopLine L Loft version.
What It Does
This hardware set enables smooth, quiet, top-running sliding doors in an overlay position. It supports:
- Widely opened doors, through offset doors (34 mm offset)
- Optional flush door configuration (0 mm offset)
- Silent System technology for quiet closing, opening, and collision handling
- Soft-closing functionality built into the opening mechanism
The system is tested to DIN EN15706, Level 3, for 40,000 opening-closing cycles, indicating durability for regular residential or light commercial use.
Who It Helps
This product is intended for:
- Modular kitchen and wardrobe fabricators specifying sliding door hardware
- Interior designers and architects selecting overlay sliding systems for wooden or aluminium-framed doors
- Furniture manufacturers building loft or wardrobe units requiring front-right screw-mounted door hardware
Key Capabilities
| Specification | Value |
|---|---|
| Door Position | Overlay |
| Track Length | 3000 mm |
| Weight Capacity per Door | 50 kg |
| Door Thickness Supported | 16–19 mm (top panel thickness ≤ 22 mm) |
| Closing Functionality | Soft Closing |
| Cycle Testing | 40,000 cycles (DIN EN15706, Level 3) |
| Maximum Door Width | 2000 mm (minimum 550 mm) |
| Maximum Door Height | 2600 mm |
| Sliding Type | Top Running |
| Door Material Compatibility | Wood / Aluminium |
| Screw Mounting | STB-12, screw from front |
| Cover Profile | No |
| Unit | Set |
| Warranty | 15 Years |
Buyer Questions This Page Should Answer
What is the maximum door size this system supports?
Up to 2600 mm height and 550–2000 mm width, with a maximum door weight of 50 kg per door.
What door thickness does this hardware fit?
Designed for 16–19 mm door thickness, with top panel thickness up to 22 mm, and specifically configured for 20 mm thick panels in this variant.
Is this suitable for wooden or aluminium doors?
Yes, the TopLine L Loft version is compatible with both wooden doors and aluminium-framed doors.
Does it include soft-close functionality?
Yes, soft closing is inbuilt via the Silent System, which dampens closing, opening, and collision movements.
How is it mounted?
This variant uses STB-12 screw-from-front mounting for the front-right door position.
What is the product SKU and price?
How durable is the sliding mechanism?
Tested to DIN EN15706, Level 3, for 40,000 opening-closing cycles, backed by a 15-year warranty.
Does it support flush-mounted doors?
Yes, flush doors (0 mm offset) are supported as an optional configuration, in addition to the standard 34 mm offset for widely opened doors.
Proof or Trust Signals
- Manufactured by Hettich, a recognized furniture hardware brand
- Tested to DIN EN15706, Level 3 standard for 40,000 cycles
- Backed by a 15-year warranty
- Part of a structured, categorized product line (TopLine L Loft version) within Hettich's Sliding Door Solutions
Resources or Next Steps
Current product facts
Last checked by Readable: 2026-09-24T07:58:24.568Z
- Product: Hettich TopLine L Loft Version (2 Door Front Right 20 mm thickness) with STB 12 (Screw from front) - Weight 50 kg per door; Max. Door Dimensions: Height 2600 mm & Width 550-2000 mm
- Brand: Hettich
- Category: Sliding Door Solutions > Top Runnning Sliding System : Overlay Door Solution > TopLine L Loft version
- SKU: 9333863.G
- Price: ₹126 (MRP ₹158)
- Availability: InStock
