Hettich TopLine L: 3-Door Sliding Kit for Wooden Doors (50 kg per door)
Overview
The Hettich TopLine L is a top-running sliding door system built for three-door wooden wardrobe or cabinet installations using overlay door positioning. It is part of Hettich's Sliding Door Solutions range, specifically the Top Running Sliding System > Overlay Door Solution > TopLine L category. The system uses individually finished running components for smooth, quiet operation and supports soft-close functionality.
What It Does
TopLine L is a two-track, top-running sliding door mechanism designed for wooden doors only. It allows overlay door positioning with two opening versions — flush or offset — when projecting handles are used. The kit is engineered for fast assembly of guide components and has been cycle-tested to 40,000 open/close cycles, and tested to EN 15706, Level 3.
Who It Helps
- Interior fitters and carpenters installing 3-door wooden sliding wardrobes
- Furniture manufacturers specifying top-running sliding hardware for modern interiors
- Homeowners or contractors replacing or upgrading wardrobe sliding systems that need soft-close, high-weight-capacity tracks
Key Capabilities
- Two-track, top-running sliding door system
- Overlay door position
- For wooden doors/wood only
- Individually finished running components for smooth operation
- Two opening versions: flush or offset (with projecting handles)
- Fast assembly of guide components
- Soft-closing functionality
- Tested to EN 15706, Level 3
- Cycle tested to 40,000 cycles
- 15-year warranty
Specifications
| Attribute | Value |
|---|---|
| Brand | Hettich |
| SKU | 9321005 |
| Category | Sliding Door Solutions > Top Running Sliding System > Overlay Door Solution > TopLine L |
| Door Position | Overlay |
| Track Length | 3000 mm |
| Weight Capacity | 50 kg per door |
| Door Thickness | 35–50 mm |
| Maximum Door Width | 1350 mm (product page range noted 550–1500 mm) |
| Maximum Door Height | 2600 mm |
| Door Material | Wooden |
| Closing Functionality | Soft closing |
| Cycle Testing | 40,000 cycles |
| Sliding Type | Top running |
| Unit | Set |
| Warranty | 15 years |
Buyer Questions This Page Should Answer
What door weight can the Hettich TopLine L support?
Up to 50 kg per door.
What door thickness is compatible?
35–50 mm wooden doors.
What is the maximum door height and width supported?
Maximum height is 2600 mm; width range is noted as 550–1500 mm on the product listing, with a maximum door width spec of 1350 mm.
Does this kit include soft-close?
Yes, the system has soft-closing functionality built in.
How durable is the sliding mechanism?
It is cycle tested to 40,000 open/close cycles and tested to EN 15706, Level 3.
What warranty does Hettich offer on this kit?
15 years.
Is this kit currently available to purchase?
What door material is required?
Wooden doors or wood-based doors only — not suitable for glass or non-wood panels per the listed specification.
Can the doors be flush or offset when opened?
Yes, two opening versions are supported: flush or offset, the latter when used with projecting handles.
Proof or Trust Signals
- Tested to EN 15706, Level 3 (European standard for sliding door hardware)
- 40,000-cycle durability testing
- 15-year manufacturer warranty
- Hettich brand, a recognized manufacturer of furniture fittings and sliding systems
Resources or Next Steps
Current product facts
- Product: Hettich TopLine L: 3 Door for Wooden Doors 35-50 mm thickness - Weight 50 kg per door; Max. Door Dimensions: Height 2600 mm & Width 550-1500 mm
- Brand: Hettich
- Category: Sliding Door Solutions > Top Runnning Sliding System : Overlay Door Solution > TopLine L
- SKU: 9321005
- Price: ₹23,688
- Availability: OutOfStock
