Hettich TopLine 1 STB-35 2-Door Sliding System (50kg per Door)
Overview
The Hettich TopLine 1 is a top-running sliding door system built for wooden doors in an inset door position. It uses a two-track design paired with the STB-35 guide system, allowing two doors to slide independently on separate tracks. It is engineered for wardrobes and cabinetry applications that need smooth, modern sliding access with wooden door panels.
What It Does
TopLine 1 carries the weight of each wooden door along a top-mounted track rather than a floor-level rail, while a bottom guide (STB 11, 12, or 35) keeps the door stable and aligned during operation. The system supports two doors on independent tracks, so each door slides freely without interference from the other.
Who It Helps
- Furniture manufacturers and modular wardrobe fabricators specifying sliding door hardware for wooden shutters.
- Interior fit-out contractors sourcing tested, warrantied sliding systems for residential or commercial storage units.
- Hardware dealers and installers who need exact load, dimension, and compatibility data before quoting a job.
Key Capabilities
- Sliding type: Top-running, two-track system
- Door position: Inset
- Door material: Wood only
- Number of doors: 2
- Guide system compatibility: STB 11, 12, and 35 bottom guides
- Testing standard: DIN EN 15706, Level 3
- Cycle testing: 40,000 cycles
- Warranty: 15 years
Specifications
| Specification | Value |
|---|---|
| SKU | 9303120.H |
| Weight capacity per door | 50 kg |
| Track length | 3000 mm |
| Maximum door width | 3000 mm |
| Maximum door height | 2500 mm |
| Minimum door height | 1500 mm |
| Door thickness supported | 16–19 mm |
| Door application | Inset |
| Door material | Wood |
| Number of doors | 2 |
| Cover profile included | No |
| Lock option | No |
| Unit of sale | Set |
Buyer Questions This Page Should Answer
What is the maximum door size this system supports?
Up to 2500 mm in height and 3000 mm in width, with a minimum height of 1500 mm.
How much weight can each door carry?
Each door can carry up to 50 kg.
What door thickness does it fit?
Doors between 16 mm and 19 mm thick.
Can this system be used with non-wood doors?
No. This specific configuration is designed for wooden doors only.
Does it include a lock or cover profile?
No. This set does not include a lock option or a cover profile.
What guide systems is it compatible with?
It can be combined with bottom guide STB 11, STB 12, or STB 35 guide systems.
How durable is the system?
It is tested to DIN EN 15706, Level 3, and rated for 40,000 open/close cycles, backed by a 15-year warranty.
Is this sold per door or per set?
It is sold as a set, covering a two-door sliding configuration.
Proof or Trust Signals
- Independently tested to DIN EN 15706, Level 3, a European standard for sliding door hardware performance.
- Rated for 40,000 operating cycles.
- Backed by a 15-year manufacturer warranty.
- Manufactured under the Hettich brand, listed under Sliding Door Solutions > Top Running Sliding System: Inset Door Solution > TopLine 1.
Resources or Next Steps
Current product facts
- Product: Hettich Topline 1: 2 Door for Wooden Doors with STB 35- Weight 50 kg per door; Max Door Dimensions : Height 1500-2500 mm & Width 500-3000 mm
- Brand: Hettich
- Category: Sliding Door Solutions > Top Runnning Sliding System : Inset Door Solution > TopLine 1
- SKU: 9303120.H
- Price: ₹60
- Availability: InStock
