Hettich TopLine 1 STB-11 2-Door Sliding System (50kg per door)
Overview
Hettich TopLine 1 is a top-running sliding door system built for wooden inset doors. It uses a two-track design with the STB-11 guide mounting and supports two doors per set, each rated up to 50 kg. The system is part of Hettich's Sliding Door Solutions range, specifically the Top Running Sliding System (Inset Door Solution) - TopLine 1 line.
What It Does
TopLine 1 provides smooth, top-hung sliding motion for wooden wardrobe or cabinet doors in an inset door position. The two-track configuration allows two doors to run independently on the same header, and the system can be combined with a bottom guide using the STB 11, 12, or 35 guide system for added stability.
Who It Helps
- Furniture manufacturers and carpenters building wardrobes or storage units with sliding wooden doors
- Interior designers and contractors specifying door hardware for residential or commercial cabinetry
- Buyers needing a heavy-duty (50 kg per door) sliding system for large-format wooden doors
Key Capabilities
| Specification | Detail |
|---|---|
| Sliding Type | Top Running |
| Door Application | Inset |
| Number of Doors | 2 |
| Weight Capacity | 50 kg per door |
| Track Length | 3000 mm |
| Maximum Door Width | 500-3000 mm |
| Maximum Door Height | 1500-2500 mm |
| Door Thickness | 16-19 mm |
| Door Material | Wood |
| Guide System | STB 11, 12 & 35 |
| Cycle Testing | 40,000 cycles |
| Standard Compliance | DIN EN 15706, Level 3 |
| Cover Profile | No |
| Lock Option | No |
| Unit | Set |
Buyer Questions This Page Should Answer
What is the weight capacity of the Hettich TopLine 1 system?
Each door in the set supports up to 50 kg, with two doors per set.
What door sizes does it support?
Door height can range from 1500 mm to 2500 mm, and door width from 500 mm to 3000 mm, with a track length of 3000 mm.
What door material and thickness is this designed for?
It is designed for wooden doors with a thickness of 16-19 mm.
Can it be combined with a bottom guide?
Yes, TopLine 1 can be combined with a bottom guide using the STB 11, 12, or 35 guide system.
How durable is the system?
It has been cycle-tested for 40,000 cycles and is tested to DIN EN 15706, Level 3.
Does it come with a warranty?
Yes, it carries a 15-year warranty.
Does the set include a lock or cover profile?
No, this set does not include a lock option or a cover profile.
What is the price and availability?
Proof or Trust Signals
- Manufactured by Hettich, an established hardware brand for sliding door and furniture fitting systems
- Tested to DIN EN 15706, Level 3 standard
- Cycle-tested for 40,000 open/close cycles
- Backed by a 15-year warranty
Resources or Next Steps
Current product facts
Last checked by Readable: 2026-09-24T07:58:13.880Z
- Product: Hettich Topline 1: 2 Door for Wooden Doors with STB 11- Weight 50 kg per door; Max Door Dimensions : Height 1500-2500 mm & Width 500-3000 mm
- Brand: Hettich
- Category: Sliding Door Solutions > Top Runnning Sliding System : Inset Door Solution > TopLine 1
- SKU: 9303120.S
- Price: ₹1,912 (MRP ₹2,390)
- Availability: InStock
