Hettich SlideLine M – 1-Door Bottom-Running Sliding System (30 kg)
Overview
Hettich SlideLine M is a 1-track, bottom-running sliding door system designed for overlay door applications. It supports wooden doors, aluminium-framed doors, and glass doors, making it suitable for wardrobes, cabinets, and similar sliding-door furniture that require a compact, sleek sliding mechanism.
What It Does
SlideLine M provides a single-track, overlay sliding mechanism at the bottom of the door, allowing smooth, silent operation. It uses a Silent System with activators that can be positioned anywhere on the track, and it supports fast, tool-free front installation.
Who It Helps
This system is intended for furniture makers, interior fabricators, and homeowners installing or replacing sliding door hardware on:
- Wooden doors
- Aluminium-framed doors
- Glass doors
It fits applications needing a 1-door (single shutter per track position) overlay sliding setup with moderate weight capacity.
Key Capabilities
- 1-track, bottom-running sliding door system
- Overlay door position
- Compatible with wood, aluminium, and glass doors
- Silent System with repositionable activators
- Tool-free front installation
- Soft-closing functionality
- Tested to DIN-EN 15706, level 3
- Rated for 40,000 open/close cycles
- 15-year warranty
Specifications
| Specification | Value |
|---|---|
| Brand | Hettich |
| Category | Sliding Door Solutions > Bottom Running Sliding System > Overlay Door Solution > SlideLine M |
| SKU | 9156338.S |
| Door Application | Overlay |
| Sliding Type | Bottom Running |
| Track Length | 2500 / 4000 mm |
| Weight Capacity per Door | 30 kg |
| Maximum Door Height | 2000 mm |
| Maximum Door Width | 300–1800 mm |
| Door Thickness Supported | 15/16 mm, 18/19 mm, 22 mm, 25 mm |
| Door Material | Wood / Aluminium / Glass |
| Closing Functionality | Soft Closing |
| Cycle Testing | 40,000 cycles |
| Cover Profile | No |
| No. of Doors | Multiple shutter |
| Unit | Set |
| Warranty | 15 Years |
Buyer Questions This Page Should Answer
What is the weight capacity of the Hettich SlideLine M?
Each door can carry up to 30 kg.
What is the maximum door size it supports?
Up to 2000 mm in height and between 300 mm and 1800 mm in width.
What door materials work with this system?
Wood, aluminium-framed, and glass doors.
Does it have soft-close functionality?
Yes, SlideLine M includes soft-closing functionality.
How durable is the mechanism?
It is tested to DIN-EN 15706, level 3, and rated for 40,000 open/close cycles.
What is the warranty?
Hettich offers a 15-year warranty on the SlideLine M system.
Is installation tool-free?
Yes, the front can be installed quickly without requiring tools.
What track lengths are available?
2500 mm and 4000 mm track lengths.
Pricing and Availability
- SKU: 9156338.S
- Unit: Sold as a set
Resources
Current product facts
Last checked by Readable: 2026-09-24T08:00:22.056Z
- Product: Hettich SlideLine M: 1 Door for Wooden & Aluminium framed Doors - Weight 30 kg per door; Max Door Dimensions: Height 2000 mm & Width 300-1800 mm
- Brand: Hettich
- Category: Sliding Door Solutions > Bottom Runnning Sliding System : Overlay Door Solution > SlideLine M
- SKU: 9156338.S
- Price: ₹2,208 (MRP ₹2,760)
- Availability: InStock
