Hettich SlideLine 55: 2-Door Bottom-Running Sliding System for Wooden Doors
Hettich SlideLine 55 is a 2-track, bottom-running sliding door system designed for inset wooden door applications. It is built to support two wooden door panels per set, each rated for up to 30 kg, and is suited for wardrobes and storage units requiring smooth, adjustable sliding motion.
Overview
- Brand: Hettich
- Category: Sliding Door Solutions > Bottom Running Sliding System > Inset Door Solution > SlideLine 55
- SKU: 9314320.G
What It Does
SlideLine 55 is a bottom-running sliding door mechanism that lets two wooden door panels glide along a 2-track aluminium runner profile. It is engineered for inset door positioning, meaning the doors sit within the cabinet frame rather than overlaying it. The system includes tool-free height adjustment and optional soft-close functionality.
Who It Helps
This system is suited for:
- Furniture manufacturers and modular kitchen/wardrobe fabricators building sliding wooden door units
- Interior fit-out contractors specifying inset sliding door hardware
- Homeowners or renovators replacing or upgrading wardrobe sliding mechanisms for wooden doors up to 1500 mm wide and high
Key Capabilities
| Feature | Detail |
|---|---|
| Door application | Inset |
| Sliding type | Bottom running |
| Track design | 2-track system |
| Track length | 3000 mm |
| Number of doors | 2 |
| Door material | Wood |
| Door thickness | 16 mm or 19 mm |
| Weight capacity | 30 kg per door |
| Maximum door width | 400–1500 mm (up to 2000 mm per spec) |
| Maximum door height | 1500 mm |
| Height adjustment | ±1 mm, tool-free |
| Opening option | Soft-closing optional |
| Cover profile | Not included |
| Cycle testing | Tested to EN 15706, Level 3; 40,000 cycles |
| Warranty | 15 years |
| Unit | Set |
Buyer Questions This Page Should Answer
What door materials work with SlideLine 55?
It is designed for wooden doors with a thickness of 16 mm or 19 mm.
How many doors does one set support?
Each SlideLine 55 set supports 2 doors.
What is the maximum door size it can handle?
Up to 1500 mm in width and 1500 mm in height, with a maximum door width specification of 2000 mm.
How much weight can each door carry?
Each door panel is rated for up to 30 kg.
Can this be used with aluminium profile doors?
No. The silent/soft-close system cannot be used with aluminium profile doors — it is intended for wooden doors only.
Does it include a cover profile?
No, a cover profile is not included with this system.
Is height adjustment possible after installation?
Yes, the system allows ±1 mm height adjustment without requiring tools.
What durability testing has it undergone?
It is tested to EN 15706, Level 3, and rated for 40,000 open/close cycles.
What warranty is offered?
Hettich provides a 15-year warranty on this system.
Is soft-close available?
Yes, soft-closing is available as an optional feature.
Proof or Trust Signals
- Manufactured by Hettich, an established hardware brand in sliding door systems
- Independently cycle-tested to EN 15706, Level 3 (40,000 cycles)
- Backed by a 15-year warranty
Resources or Next Steps
Current product facts
- Product: Hettich SlideLine 55: 2 Door for Wooden Doors - Weight 30 kg/door - Alu Runner Profile Max Door Dimensions: Height 1500 mm & Width 400-1500 mm
- Brand: Hettich
- Category: Sliding Door Solutions > Bottom Runnning Sliding System : Inset Door Solution > SlideLine 55
- SKU: 9314320.G
- Price: ₹17
- Availability: InStock
