Hettich KA 5740 Sliding Shutter System (8 kg per Shutter)

Overview

The Hettich KA 5740 is a special sliding fitting system designed for wooden sliding shutters/doors, supporting up to 8 kg per shutter. It falls under Hettich's Sliding Door Solutions > Special Sliding Fittings range and is built for compact cabinet and wardrobe applications requiring smooth, secure sliding door movement.

What It Does

The KA 5740 system enables smooth, secure sliding operation for wooden cabinet or wardrobe doors. It includes a roll-out locating catch that ensures the door closes securely and operates smoothly across its full width range. The system is tested to the ANSI/BIFMA X5.5 durability standard.

Who It Helps

• Furniture manufacturers and carpenters fitting sliding wooden doors on cabinets or wardrobes
• Interior fit-out contractors sourcing hardware for modular furniture
• Retail buyers or homeowners replacing or upgrading sliding shutter fittings

Key Capabilities

• Supports wooden doors up to 8 kg per shutter
• Door height up to 1500 mm
• Door width from 300 mm to 600 mm
• Door thickness 16-19 mm
• Roll-out locating catch for smooth operation and secure closure
• Tested to ANSI/BIFMA X5.5
• Minimum cabinet internal depth: 326 mm (for the 300 mm channel length variant)

Product Variants

Available Channel Lengths

300 mm, 350 mm, 400 mm, 450 mm, 500 mm, 550 mm, 600 mm, 650 mm, 700 mm

Pricing and Availability

Buyer Questions This Page Should Answer

What weight can the KA 5740 support?

Up to 8 kg per shutter.

What door sizes is it compatible with?

Door height up to 1500 mm and door width from 300 mm to 600 mm, with door thickness between 16 mm and 19 mm.

Is it suitable for any door material?

It is designed specifically for wooden doors.

What channel length should I choose?

Channel lengths range from 300 mm to 700 mm; select based on your cabinet's internal depth and door width. For the 300 mm channel length variant, the minimum cabinet internal depth required is 326 mm.

Does it come with a warranty?

Yes, the KA 5740 sliding system carries a 10-year warranty.

Is the 300 mm-only version currently available?

What quality standard is it tested to?

ANSI/BIFMA X5.5.
