Hettich HSA 10 F: EN 2/3/4 Surface Mounted Door Closer with Slide Rail

Overview

The Hettich HSA 10 F is a surface mounted, standard arm door closer with a slide rail, designed for doors weighing 40-80 kg and widths of 850-1100 mm. It is fire rated (EN 2/3/4 classification) and uses a rack and pinion (symmetric) mechanism to provide smooth, controlled closing and prevent doors from being left ajar.

What It Does

This door closer controls the closing motion of medium to heavy doors, offering continuously adjustable closing and latching speeds. It is suited for commercial, institutional, or heavy residential doors that require fire-rated closing hardware with a standard arm and slide rail configuration.

Who It Helps

• Architects, contractors, and facility managers specifying fire-rated door hardware
• Hardware dealers and distributors sourcing Hettich door closers
• Buyers replacing or upgrading closers on doors in the 850-1100 mm width and 40-80 kg weight range

Key Capabilities

• Mechanism: Rack and pinion (symmetric) door closer
• Fire rating: EN 2/3/4 classification
• Door weight capacity: 40-80 kg
• Door width range: 850-1100 mm
• Closing speed: Continuously adjustable, works between 180° and 0°
• Latching speed: Continuously adjustable, approx. 10° to 0°
• Cycle testing: Tested and certified for 200,000 cycles
• Finish: Silver
• Body material: Cast aluminium
• Warranty: 2 years
• Net content: 1 closer body and 1 standard arm

Product Facts

Buyer Questions This Page Should Answer

What door sizes is the HSA 10 F designed for?

It is built for doors between 850 mm and 1100 mm wide, weighing 40 to 80 kg.

Is this door closer fire rated?

Yes, it carries an EN 2/3/4 fire rating, making it suitable for fire door applications.

What mechanism does it use?

A rack and pinion (symmetric) mechanism that allows continuously adjustable closing speed (180° to 0°) and latching speed (approx. 10° to 0°).

What is included in the package?

One closer body and one standard arm (slide rail configuration).

What is the warranty and durability testing?

The closer is tested and certified for 200,000 cycles and comes with a 2-year warranty.

What is the finish and material?

Cast aluminium body with a silver finish.

Is it currently available to purchase?

Proof or Trust Signals

• Cycle tested and certified for 200,000 operations
• 2-year manufacturer warranty
• EN 2/3/4 fire rating classification
• Branded Hettich hardware with defined SKU (9227816)

Resources or Next Steps

• View product page
• Browse Hettich Fittings online
