Hettich HBC-34-1845/246Z-3D: 3D-Concealed Hinge, Matt Black
Overview
The Hettich HBC-34-1845/246Z-3D is a 3D-concealed cabinet door hinge designed to sit discreetly behind the door for smooth, silent operation. It is built from zinc alloy die-cast material with SS 304 connecting flanges and finished in Matt Black. The hinge supports a loading capacity of up to 120 kg per pair and includes 3-dimension adjustment for precise door alignment.
What It Does
This concealed hinge attaches inside cabinetry and furniture doors, staying hidden when the door is closed. The 3D adjustment mechanism (height, depth, and side-to-side) lets installers fine-tune door alignment after mounting. It opens to 180 degrees and is rated for 200,000 operating cycles.
Who It Helps
- Modular kitchen and wardrobe fabricators sourcing heavy-duty concealed hinges
- Interior contractors and carpenters fitting cabinet doors requiring precise alignment
- Homeowners and renovators replacing or upgrading cabinet hardware with a matte black finish
Key Product Facts
| Attribute | Detail |
|---|---|
| Brand | Hettich |
| Model | HBC-34-1845/246Z-3D |
| Category | Door Hinges > Concealed Hinges |
| Finish | Matt Black |
| Material | Zinc alloy die-cast body with SS 304 connecting flanges |
| Loading Capacity | Up to 120 kg per pair |
| Min Door Thickness | 45 mm |
| Opening Angle | 180 degrees |
| Cycle Rating | 200,000 cycles |
| Adjustment | 3-dimension (3D) alignment |
| Warranty | 5 years |
| Unit | 1 pair (hinges with screws) |
| Country of Origin | China |
| Hole Pattern | No drilling pattern (SKU 9251128_P listing) |
Pricing and Availability
This hinge is listed under two SKUs on the Hettich India online store, differing in price and stock status:
Buyers should confirm current stock and pricing directly on the product page before ordering, since one SKU is currently unavailable.
Variants Available
- Weight Capacity: 40 kg
- Weight Capacity: 80 kg
- Weight Capacity: 120 kg
- Finish Type: Matt Black
- Finish Type: Silver
Buyer Questions This Page Should Answer
What loading capacity does this hinge support?
Up to 120 kg per pair, with lower-capacity variants (40 kg and 80 kg) also available.
What is the minimum door thickness required?
45 mm minimum door thickness for the 120 kg Matt Black variant.
What finish options are offered?
Matt Black and Silver finish types are available across the hinge range.
How many operating cycles is the hinge rated for?
200,000 cycles.
What materials is the hinge made from?
Zinc alloy die-cast body with stainless steel (SS 304) connecting flanges.
What warranty is included?
5-year warranty.
Does it come with mounting hardware?
Yes, net content includes hinges with screws, packaged as 1 pair.
Where is the product manufactured?
Country of origin is China.
Resources
Current product facts
Last checked by Readable: 2026-09-26T18:46:49.371Z
- Product: Hettich 3D Concealed Hinges
- Brand: Hettich
- Category: Door Hinges > Concealed Hinges > Other Categories
- SKU: 9251128_P
- Price: ₹5,302.9 (MRP ₹5,582)
- Availability: InStock
- Variants: Weight Capacity: 40 Kg, Weight Capacity: 80 Kg, Weight Capacity: 120 Kg, Finish Type: Matt Black, Finish Type: Silver
