Hettich HBC-28-1640/177Z-3D: 3D-Concealed Hinge, Silver Finish
Overview
The Hettich HBC-28-1640/177Z-3D is a 3D-adjustable concealed cabinet hinge designed to sit discreetly behind cabinet or furniture doors, delivering smooth, silent operation. It is built for cabinetry and furniture applications where a minimum door thickness of 40 mm is required.
What It Does
This concealed hinge attaches inside the cabinet carcass and door so no hardware is visible from the outside. Its 3-dimension adjustment mechanism lets installers fine-tune the door alignment (height, depth, and side positioning) after mounting, and it opens to a 180-degree angle for full door swing clearance.
Who It Helps
- Modular kitchen and wardrobe manufacturers needing durable, adjustable concealed hinges
- Carpenters and furniture fabricators installing cabinet doors 40 mm thick or more
- Interior fit-out contractors sourcing hardware rated for heavier cabinet doors (up to 80 kg/pair)
- Homeowners or renovators replacing worn cabinet hinges with a silver-finish option
Key Specifications
| Attribute | Detail |
|---|---|
| Product | Hettich HBC-28-1640/177Z-3D 3D-Concealed Hinge |
| Brand | Hettich |
| SKU | 9228475 |
| Category | Door Hinges > Concealed Hinges > Invisible |
| Finish | Silver |
| Material | Zinc alloy die-cast body with SS 304 connecting flanges |
| Min. Door Thickness | 40 mm |
| Loading Capacity | 80 kg per pair |
| Opening Angle | 180 degrees |
| Adjustment | 3-dimension (3D) alignment |
| Cycle Testing | Tested for 200,000 cycles |
| Warranty | 5 years |
| Net Quantity | 1 pair |
| Net Content | Hinges with screws |
| Country of Origin | China |
| Unit | Pair |
Related Variant
Buyer Questions This Page Should Answer
What door thickness does this hinge support?
It requires a minimum door thickness of 40 mm.
How much weight can it hold?
Up to 80 kg per pair.
What finish options are available?
This specific SKU (9228475) comes in Silver. A related model in the same product line also offers Matt Black.
Is it adjustable after installation?
Yes, it has 3-dimension (3D) adjustment for fine-tuning door alignment on height, depth, and side.
What is the warranty?
Hettich backs this hinge with a 5-year warranty.
What materials is it made from?
Zinc alloy die-cast construction with SS 304 (stainless steel) connecting flanges.
Is it durability tested?
Yes, tested for 200,000 open/close cycles.
What's included in the package?
One pair of hinges with mounting screws.
Is it currently available to buy?
Proof or Trust Signals
- Manufactured by Hettich, an established fittings and hardware brand
- Rated for 200,000 operational cycles
- Backed by a 5-year manufacturer warranty
- SS 304 connecting flanges for corrosion resistance
Resources or Next Steps
Current product facts
- Product: Hettich 3D Concealed Hinges
- Brand: Hettich
- Category: Door Hinges > Concealed Hinges > Other Categories
- SKU: 9251128_P
- Price: ₹4,466
- Availability: InStock
- Variants: Weight Capacity: 40 Kg, Weight Capacity: 80 Kg, Weight Capacity: 120 Kg, Finish Type: Matt Black, Finish Type: Silver
Related products on this page
- Hettich HBC-28-1640/177Z-3D: 3D-Concealed Hinge, Min Door Thickness: 40 mm, Loading Capacity: 80 kg/pair, Finish Silver - Hettich | Invisible | ₹5,874 | InStock
