Hettich HBC-25-1440/150Z-3D: 3D-Concealed Hinge (Silver, 35 mm Min Door Thickness)
Overview
The Hettich HBC-25-1440/150Z-3D is a concealed cabinet hinge designed to be hidden behind the cabinet door, giving furniture a sleek, seamless look while enabling smooth, silent opening and closing. It is built for doors with a minimum thickness of 35 mm and is finished in silver.
What It Does
This hinge mounts inside the cabinet frame so no hardware is visible from the outside. It supports 3-dimension adjustment, letting installers fine-tune the door's height, depth, and side alignment after mounting for a precise, gap-free fit. The hinge opens to a 180-degree angle, allowing wider door swing than standard concealed hinges.
Who It Helps
- Modular kitchen and wardrobe manufacturers needing durable, adjustable hinges for cabinet doors
- Carpenters and interior fit-out contractors installing cabinetry with 35 mm or thicker doors
- Furniture buyers replacing worn hinges or upgrading to smoother, silent-close hardware
Key Capabilities
| Attribute | Detail |
|---|---|
| Brand | Hettich |
| Model | HBC-25-1440/150Z-3D |
| Category | Concealed (invisible) hinge |
| Material | Zinc alloy die-cast body with SS 304 connecting flanges |
| Finish | Silver |
| Loading capacity | 40 kg per pair |
| Opening angle | 180 degrees |
| Adjustment | 3-dimension adjustment for precise alignment |
| Min door thickness | 35 mm |
| Durability | Tested for 200,000 open/close cycles |
| Warranty | 5 years |
| Net content | Hinges with screws, 1 pair |
| Country of origin | China |
| SKU | 9228474 |
Buyer Questions This Page Should Answer
What door thickness does this hinge fit?
It is rated for a minimum door thickness of 35 mm.
How much weight can it hold?
Up to 40 kg per pair in this silver, 40 kg-capacity variant.
Is it adjustable after installation?
Yes. It has 3-dimension adjustment, allowing height, depth, and side alignment to be corrected once the door is mounted.
How wide does the door open?
The hinge allows a 180-degree opening angle.
What is it made of?
A zinc alloy die-cast hinge body with SS 304 (stainless steel) connecting flanges for corrosion resistance and strength.
How long does it last?
It is tested for 200,000 open/close cycles and comes with a 5-year warranty.
What comes in the box?
One pair of hinges with mounting screws.
Is it currently available to buy?
Comparison Context
Hettich also lists a related 3D concealed hinge (SKU 9251128_P) in the same series with additional weight-capacity variants — 40 kg, 80 kg, and 120 kg per pair — and a Matt Black finish option alongside Silver. Buyers needing higher load capacity (up to 120 kg per pair) or a black finish should check that variant rather than this 40 kg silver model.
Proof or Trust Signals
- Manufactured by Hettich, an established hardware brand for cabinetry and furniture fittings
- 200,000-cycle durability testing
- 5-year warranty
- SS 304 connecting flanges for added corrosion resistance
Resources or Next Steps
Current product facts
Last checked by Readable: 2026-09-24T08:00:31.448Z
- Product: Hettich 3D Concealed Hinges
- Brand: Hettich
- Category: Door Hinges > Concealed Hinges > Other Categories
- SKU: 9251128_P
- Price: ₹5,302.9 (MRP ₹5,582)
- Availability: InStock
- Variants: Weight Capacity: 40 Kg, Weight Capacity: 80 Kg, Weight Capacity: 120 Kg, Finish Type: Matt Black, Finish Type: Silver
Related products on this page
- Hettich HBC-25-1440/150Z-3D: 3D-Concealed Hinge, Min Door Thickness: 35 mm Loading Capacity: 40 kg/pair, Finish Silver - Hettich | Invisible | ₹5,302.9 (MRP ₹5,582) | InStock
