Hettich Grant 1260 with 3000 mm Runner (For Heavy Duty Folding Doors) - 80 Kg / Door
Overview
The Hettich Grant 1260 is a top-mounted sliding door hardware system built for heavy-duty bi-fold and folding door applications. It uses a 3000 mm track and supports up to 80 Kg per door, making it suitable for room dividers and large wooden folding door installations that need stable, quiet movement.
What It Does
Grant 1260 mounts at the top of the door opening and carries the door weight on a precision 4-wheel carrier with ball bearing wheels, allowing the door to slide and fold smoothly with minimal noise. The track is pre-drilled for faster installation, and the system supports both one-way and bi-parting configurations depending on the layout.
Who It Helps
- Carpenters, fabricators, and interior contractors installing heavy wooden folding or bi-fold doors
- Homeowners or architects specifying room divider systems that need to handle heavier door panels
- Buyers who need a top-hung sliding-folding mechanism rather than a bottom-track system
Key Capabilities
- Mounting type: Top-mounted sliding door system
- Application: Bi-fold folding doors
- Carrier: 4-wheel carrier with precision ball bearing wheels for quiet, effortless operation
- Installation: Pre-drilled track for easy fitting
- Configuration: One-way or bi-parting sets available
- Standards: Conforms to ANSI/BHMA standards
- Warranty: 10 years
Product Specifications
| Spec | Value |
|---|---|
| Track Length | 3000 mm |
| Weight Capacity per Door | 80 Kg |
| Maximum Door Height | 3000 mm |
| Door Thickness Supported | 25.4 mm |
| Sliding Type | Sliding and folding |
| Door Material | Wood |
| Number of Doors | 1 |
| Cover Profile | No |
| Lock Option | No |
| Headroom Required | 3¼" (82.5 mm) min. to 3¾" (95.2 mm) max. |
| Unit | Set |
| Country of Origin | India |
| SKU | 9308610.S |
Pricing and Availability
- Brand: Hettich
- Category: Sliding Door Solutions > Sliding Solutions for Room Divider System > Grant 1260
Buyer Questions This Page Should Answer
How much weight can the Grant 1260 support?
Each door can carry up to 80 Kg using the 3000 mm track.
What door material and thickness does it support?
It is designed for wood doors with a thickness of 25.4 mm.
Is it suitable for bi-fold doors?
Yes, the system is built specifically for bi-fold folding door applications, with one-way or bi-parting set options.
How much headroom is needed for installation?
A minimum of 3¼" (82.5 mm) and maximum of 3¾" (95.2 mm) headroom is required for top mounting.
Does it include a lock or cover profile?
No, this set does not include a lock option or cover profile.
What is the warranty?
The Grant 1260 carries a 10-year warranty.
Does it meet any hardware standards?
Yes, it conforms to ANSI/BHMA standards.
Resources
Current product facts
- Product: Hettich Grant 1260 with 3000 mm Runner (For Heavy Duty Folding Doors) - 80 Kg / Door
- Brand: Hettich
- Category: Sliding Door Solutions > Sliding Solutions for Room Divider System > Grant 1260
- SKU: 9308610.S
- Price: ₹912
- Availability: InStock
