Hettich 55 mm Straight Frame Profile with F Handle (3000 mm)

The Hettich 55 mm Straight Frame Profile with F Handle is an aluminium frame profile used to build glass shutter doors for wardrobes, cabinets, and furniture. It is sold in a 3000 mm length and is available in two glass-thickness configurations with multiple finish options.

What It Does

This profile forms the frame around a glass panel, allowing the panel to function as a shutter or door. It includes an integrated F Handle for opening the shutter. Angle connectors, which join the profile lengths into a finished frame, must be purchased separately.

Who It Helps

• Modular furniture and wardrobe manufacturers building glass shutter doors
• Interior fit-out contractors and carpenters sourcing Hettich aluminium hardware
• Retailers and dealers stocking Hettich profile systems for resale

Product Variants

Hettich lists this profile in two SKU configurations based on glass thickness:

Finish options available (for the 4 mm variant): Stainless Steel, Silver anodized, Dark champagne, Black.

The 8 mm variant shown is in Black finish.

Key Specifications

• Brand: Hettich
• Profile type: Straight Frame Profile
• Width of profile: 55 mm
• Length of profile: 3000 mm
• Handle type: F Handle
• Material: Aluminium
• Package content: 1 number (1 piece)
• Warranty: 20 years
• Country of origin: India
• Manufacturer/Importer: Hettich Indore (for the 8 mm Black variant)
• Package dimension: 100 x 75 x 3020 mm (8 mm Black variant)

Glass Sizing Guidance

Glass panel size is calculated from the finished frame dimensions:

• Glass height = Frame height − 7 mm
• Glass width = Frame width − 7 mm

Buyer Questions This Page Should Answer

What glass thickness does this profile support?

Two configurations are available: one for 4 mm thick glass panels (SKU 9340572_P) and one for 8 mm thick glass panels (SKU 9340560, Black finish).

Do I need to buy anything else to complete the frame?

Yes. Angle connectors, used to join the profile lengths at the corners, are procured separately and are not included with the profile.

What finishes are available?

Stainless Steel, Silver anodized, Dark champagne, and Black.

What length does the profile come in?

This listing is for the 3000 mm length.

Is there a warranty?

Yes, Hettich provides a 20-year warranty on this profile.

How do I size the glass panel for this frame?

Subtract 7 mm from both the frame height and frame width to get the required glass panel height and width.

Is this currently available to order?

Resources

• Product page: Hettich 55 mm Straight Frame Profile with F Handle
• Hettich India
