Hettich 45 mm Straight Frame Profile with L Handle (3000 mm, Stainless Steel Finish)

Overview

This is an aluminium straight frame profile from Hettich, designed to frame 4 mm thick glass panels for cabinet doors and similar applications. It comes with an L Handle, is 3000 mm long, and is available with a Stainless Steel finish. The profile carries a 20-year warranty.

What It Does

The profile forms the frame around a 4 mm thick glass panel, giving the panel structural edging and a handle grip in one piece. Angle connectors, needed to join profile lengths at corners, are sold separately and must be procured independently.

Who It Helps

This product is intended for:

• Modular kitchen and furniture fabricators building glass-front cabinet doors
• Carpenters and interior contractors sourcing Hettich aluminium profile systems
• Homeowners or designers specifying glass-panel cabinet doors with a metal frame and integrated handle

Key Capabilities

• Profile type: Straight Frame Profile
• Handle type: L Handle
• Width of profile: 45 mm
• Length of profile: 3000 mm
• Glass thickness supported: 4 mm
• Finish: Stainless Steel
• Material: Aluminium
• Package content: 1 number (piece)
• Warranty: 20 years

Available Listings

Hettich lists this profile family under two related SKUs with different pricing, finish scope, and country of origin:

Both SKUs share the same core profile specifications: 45 mm width, 3000 mm length, 4 mm glass thickness compatibility, and a 20-year warranty.

Sizing Guidance

Glass panel size should be calculated as:

• Glass height = Frame height minus 7 mm
• Glass width = Frame width minus 7 mm

This 7 mm deduction accounts for the profile's grip on the glass edge and must be factored in when ordering cut glass panels for this frame.

Buyer Questions This Page Should Answer

What glass thickness does this profile support?

It is built for 4 mm thick glass panels only.

Do I need to buy anything else with this profile?

Yes. Angle connectors, used to join profile pieces at corners, are not included and must be purchased separately.

What finishes are available?

SKU 9310256_P offers five finishes: Stainless Steel, Silver anodized, Copper, Dark champagne, and Black. SKU 9307830 is available specifically in Stainless Steel with an L Handle.

What is the difference between the two listed SKUs?

What is the warranty?

Each profile carries a 20-year warranty from Hettich.

How long is the profile?

The profile length is 3000 mm, sold as 1 piece per package.
