Hettich 45 mm Straight Frame Profile – 3000 mm, Silver Finish
Overview
The Hettich 45 mm Straight Frame Profile is an aluminium framing profile designed to hold 4 mm thick glass panels in cabinet doors, partitions, and architectural glass applications. This listing covers the 3000 mm length in Silver anodized finish, sold under SKU 9283473, with a related multi-finish variant group listed under SKU 9310254_P.
What It Does
This profile forms the frame around a glass panel, giving glass doors and panels a clean, finished edge. It is sized for 4 mm glass and requires separate angle connectors to complete a frame assembly (corners are not included).
Key Product Facts
| Attribute | Detail |
|---|---|
| Brand | Hettich |
| Category | Aluminium Profiles > 45 mm Aluminium Profiles |
| Profile Type | Straight Frame Profile |
| Width of Profile | 45 mm |
| Length of Profile | 3000 mm |
| Glass Thickness Supported | 4 mm |
| Finish Type | Silver anodized |
| Material | Aluminium |
| Package Content | 1 Number (Unit: Piece) |
| Warranty | 20 Years |
| SKU | 9283473 |
| Country of Origin | China (this SKU); Germany (multi-finish variant SKU 9310254_P) |
Available Finishes
The profile family is available in multiple finishes, including:
- Stainless Steel
- Silver anodized (this listing)
- Copper
- Dark champagne
- Black
Sizing Guidance
Glass size should be calculated as:
- Glass Height = Frame height − 7 mm
- Glass Width = Frame width − 7 mm
This accounts for the profile's groove depth when fitting the glass panel into the frame.
Who It Helps
- Cabinet and furniture manufacturers building glass-front doors or panels
- Interior fit-out contractors assembling glass partitions or display frames
- Hardware retailers and distributors sourcing Hettich aluminium profile systems
- Architects and designers specifying finished edge profiles for 4 mm glass
Buyer Questions This Page Should Answer
What glass thickness does this profile fit?
It is designed for 4 mm thick glass panels only.
Do I need extra parts to build a full frame?
Yes. Angle connectors (corner joiners) must be purchased separately; they are not included with the profile.
What length does this profile come in?
This listing is for the 3000 mm length. Buyers should cut or order to the length needed for their frame, accounting for the glass sizing offset.
What finish options are available?
Silver anodized is the finish for this specific listing. The same 45 mm profile is also available in Stainless Steel, Copper, Dark champagne, and Black finishes.
Is this profile covered by warranty?
Yes, it carries a 20-year warranty from Hettich.
Comparison Context
This 45 mm Straight Frame Profile sits within Hettich's broader Aluminium Profiles range for glass framing. Buyers choosing between finishes (Silver, Black, Copper, Dark champagne, Stainless Steel) should confirm which finish and country-of-origin variant matches their project before ordering, since SKU and origin can differ by finish option.
Proof or Trust Signals
- Branded and sold directly through Hettich Fittings' official online store
- Backed by a 20-year warranty
- Clearly specified technical dimensions (profile width, glass thickness, length) for accurate project planning
Resources or Next Steps
Current product facts
Last checked by Readable: 2026-10-07T18:46:52.868Z
- Product: Hettich 45 mm Straight Frame Profile 3000 mm (2)
- Brand: Hettich
- Category: Aluminium Profiles > Deals > Other Categories > 45 mm Aluminium Profiles
- SKU: 9310254_P
- Price: ₹3,108 (MRP ₹5,180)
- Availability: InStock
- Variants: Finish Type: Stainless Steel, Finish Type: Silver anodized, Finish Type: Copper, Finish Type: Dark champagne, Finish Type: Black
